010-02816-01 Garmin Cortex H1P Portable Handset
010-02816-01 Garmin Cortex H1P Portable Handset - Image 2
010-02816-01 Garmin Cortex H1P Portable Handset - Image 3

010-02816-01 Garmin Cortex H1P Portable Handset

SKU: 010-02816-01

$1,048.99 Inc. GST

H1-n-H1P-Cortex-Vesper_Marine_Cortex_Handset_Quick_Start_Guide_English_09_07_20_WEB.pdf Vesper_Marine_Cortex_Handset_Quick_Start_Guide_English_09_07_20_WEB-1.pdf H1P_Handset_Instructions_EN-US-1.pdf Product-Overview_Cortex_1.3_GLOBAL.pdf 2022-Vesper-Marine_Catalogue_SEP21_WEB.pdf

010-02816-00 Garmin Cortex H1P Portable Handset

Description: Paired with your Cortex hub, the Cortex H1 tethered or H1P portable handset serves as the control and voice-calling interface for VHF, DSC calling and AIS display of potential collision risks.
You can optionally add extra Cortex handsets (sold separately) for even more freedom and control on board.
Compatibility:
  • Cortex V1 VHF AIS
  • Cortex M1 AIS
In this pack – Cortex H1P
  • H1 Handset
  • H1 Handset Cradle
  • H1P Handset Charging Cradle

SINGLE-HANDED CONTROL FOR YOUR CORTEX® SYSTEM

Available in tethered and portable versions, Cortex touchscreen handsets are the ultimate interface for your Cortex system. They put the best in VHF communications and AIS situational awareness right at your fingertips — no matter where you are on your boat.

Add multiple Cortex handsets to a Cortex V1 or VHF-ready Cortex M1 hub for more control in more places.

Enjoy easy one-hand operation with your handset’s touchscreen, click-wheel and dedicated select keys.

The handset’s high-fidelity speaker delivers up to 85 dBA of crystal-clear audio for superior VHF communication.

You can quickly initiate DSC direct calls by tapping the AIS boat symbol on the handset’s touchscreen.

Communicate and control from anywhere onboard with Wi-Fi® handset connectivity to your Cortex hub.

The unit’s 4″ touchscreen and rugged case are built to withstand harsh, wet marine environments.

NOTE: Engineering enhancements are ongoing and may not be reflected in the pictures, videos and specifications.

Garmin – H1P Portable Handset
Unit size 164.8 x 71.8 x 21.4 mm (6 1/2″ x 2 13/16″ x 7/8″)
Weight H1: 285 g (0.63 lb)
H1P: 235 g (0.52 lb)
Water rating IPX8 (water submersion rating to 10’)
Battery type H1: No battery
H1P: Lithium polymer, 2 hour full charge, > 10 hours minimal operation
Operating voltage 12-24V compatible
Current draw 12V, 1A max, 200mA m
Operating temperature -25°C to +55°C (-13°F to 131°F)

Sensors
Ambient light sensor

Audio
Amplifier 3W Class D amplifier, THD < 5% @ 85 dBA
Built-in microphone

Display
Screen LCD TFT Si, 640 x 800, 24-bit colour
Touch Capacitive, optically-bonded to LCD
Touch feature Glove and salt water operable
Cable length 6 ft (2 m)
Channel 16 shortcut

Instrument Features
Backlight 600 cd/m2

*6 ft (2 metres) cable length applies to H1 headset only
