15002-02-02 Flir Marine Scout Pro Hand-held Thermal Camera, Monocular 30Hz
$4,076.60 Inc. GST
15002-02-02 Flir Marine Scout Pro Hand-held Thermal Camera, Monocular 30Hz
The FLIR Ocean Scout Pro is a marine thermal night vision monocular, designed for enhanced situational awareness on the water.
Hand-held Portable FLIR Vision
Use Ocean Scout Pro to navigate confidently at night, identify navigation aids and find people in the water. Featuring a wide 32° field-of-view, Ocean Scout Pro allows for rapid area sweeps and detecting human heat signatures up to 500 meters away. Operating the Ocean Scout Pro is easy.
A streamlined user interface and ergonomic controls ensure a continuous view of targets, persons or scenes without distracting menus and settings. Advanced image enhancements improve human and navaid detection, ensuring you never miss a target.
Human detection range – 500 m (540 yards)
15002-02-02 Included in this Pack
- Camera Unit: Ocean Scout Pro, 30Hz Refresh Rate
- Lanyard
- USB Sync and charge cable
- Tactical Storage Pouch with Molly Compatible Webbing
- 2pcs Rubber Eye Cups
- Documentation Pack
Basic Specs
- Size (L x W x H): 192 × 64 × 64mm (7.5 × 2.5 × 2.5in)
- Weight (incl. internal battery): 498 g (1 lb 2 oz)
- Tripod mounting: UNC ¼”-20
- IP Rating: IP67
- Drop Rating: 2m(6.7ft)
Features and Benefits
- Navigate at night with confidence
- Up to 500 m visibility, even in the dark
- Wide 32° field of view for maximum coverage and faster area sweeps
- Rugged and reliable with IP67 rating and 2 m drop protection
- Easy-to-use menu, requiring minimal training
- Wireless video streaming through Scout Pro App (iOS only)
- Avoid obstacles, floating debris and navigate safer
- Locate navigation aids
- Find people or pets in the water
Marine Law Enforcement and Govt Applications
- Active pursuit
- Search and rescue
- Surveillance
- Evidence gathering
Mission Ready – We developed Ocean Scout Pro in collaboration with public safety professionals; it’s built to withstand harsh marine environments, deploy rapidly, and meet the demands of marine law enforcement, coastguards, and search and rescue operators.
Intuitive one-finger button activation combined with a streamlined user interface, let officers stay focused on critical targets.
With up to 6 hours of battery life, Ocean Scout Pro is always ready.
Get Underway with Confidence – Built for the harsh marine environment, Ocean Scout Pro helps you navigate at night and assist in search and rescue, and public safety operations.
Easy to Use – Ready in seconds with an intuitive interface, single-handed operation, and effortless control, even in high-pressure situations.
See More, Navigate Safer
Extend your time on the water and feel safer in low light conditions with handheld thermal imaging. The Ocean Scout Pro provides boaters with a wide 32° field of view lens, optimized for on-water observation. Spot obstacles and navigation aids in total darkness and navigate with confidence. Should a passenger or pets go overboard, FLIR image-enhancing technology can help you to locate them in the water up to 500 meters away.
FLIR Ocean Scout Pro – SPECIFICATIONS
| General | |
|---|---|
| Field of View (FOV) | 32° |
| Focal length | 19 mm |
| F-number | f/ 1.0 |
| Focus | Fixed focus |
| Human detection range | 500 m (540 yards) |
| Minimum focus distance | 4 m (13 ft) |
| Detector frame rate | 30 Hz |
| Display frame rate | 60 Hz |
| Spectral range | 7.5 μm – 13.5 μm |
| Pixel pitch | 17 μm |
| Thermal sensitivity, NETD | <38 mK @ 30°C (86°F) |
| Resolution | 640 ×480, vox microbolometer |
| Image processing | FLIR proprietary Digital Detail Enhancement™ |
| Color (housing) | Silver/Black |
| Drop rating | 2 m (6 ft 7 in) |
| IP rating | IP67 |
| User Interface | |
|---|---|
| Zoom | 2x, 4x, 6x, 8x |
| Modes | White Hot, Black Hot, Sepia |
| Disable radio and Wi-Fi | Physical On/Off switch |
| Image Presentation | |
|---|---|
| Built-in display | XGA 1024 × 768 |
| Video | XGA 1024 × 768 |
| Power | |
|---|---|
| Battery life | Up to 6 hours |
| Battery type | Internal Li-Ion cell |
| Charging time | 2 h at 80% |
| Physical | |
|---|---|
| Size (L x W x H) | 19.2 cm × 6.4 cm × 6.4 cm (7.5 in × 2.5 in × 2.5 in) |
| Weight (incl. battery) | 498 g (1 lb 2 oz) |
| Tripod mounting | UNC ¼”-20 |
| Image Storage | |
|---|---|
| Media gallery | Scout Pro App (iOS only) |
| Storage media | Embedded flash |
| Image storage capacity | >1000 |
| Image storage mode | IR |
| File formats | Standard JPEG |
| Video recording | Yes |
| Non-radiometric IR video recording | MPEG4 AVC (ITU-T H.264) |
| Storage capacity | 16 GB |
| Video streaming | Yes |
| Non-radiometric IR video streaming | Wi-Fi/RTSP (MPEG4 AVC (ITU-T H.264)) |
| USB streaming | UVC (YUV422 no overlay) |
| Wireless Connectivity | |
|---|---|
| Bluetooth | BLE |
| Streaming | Wi-Fi |
