B3-402Q Intellian i4 Global Satellite TV Antenna System, 45cm Ku-band
Most Popular Size Marine Satellite TV Antenna System
$8,228.00 Inc. GST
B3-402Q Intellian i4 Global Satellite TV Antenna System, 45cm Ku-band
Power and Efficiency
45cm (18inch) Reflector Ku-band Satellite TV System
Power and efficiency make the i4 the most popular 45 cm (18 inch) Satellite TV system for pleasure boats, fishing boats, workboats, and commercial vessels approximately 12m (35ft) to 20 (60ft) in length. With Intellian’s proprietary iQ² technology, the i4 offers the most precise tracking capabilities and superior satellite signal reception while the vessel is cruising at high speed or in rough sea conditions.
iQ²: Quick & Quiet℠ Technology
iQ² Technology allows you to tune in quickly, maintain a solid signal lock, and enjoy your favorite TV programming in quiet comfort reducing power consumption and wear and tear on the antenna.
Works with All Providers
Compatible with leading Ku-band satellite TV service providers around the world.
Triple Sat Function
Auto satellite switching function for three satellites.
Automatic Skew Control
The available i4P version is equipped with Automatic Skew Control, which allows for better satellite tracking on vessels operating over greater distances in areas served by Linear Satellite TV signals (Europe and South America).
KEY FEATURES
Fully Automated System
Automatic satellite search and identification.
2-axis step motors to stabilize the pedestal.
Enhanced Antenna
Highly efficient parabolic antenna enables 49dBW of minimum EIRP.
RHCP / LHCP, Vertical / Horizontal polarization
Wide Range Search (WRS) Algorithm
Competitor methods search for the narrow-bandwidth of the main lobe. However Intellian’s exclusive WRS searches for the wide range of side lobes and jumps up to the main lobe, providing faster satellite acquisition.
Dynamic Beam Tilting (DBT) Technology
A high-speed sub-reflector rotates off axis, checking signal strength at 50 times per second and compensating the tracking direction. Less movement of the main-reflector means less noise and extends the product life.
DVB-S2 Signal Identification
High speed identification employing DVB-S2 Decoder.
New Type Antenna Control Unit
• Intuitive controls with a digital information display on the ACU
• Wireless automated updates and diagnostics via Aptus PC and Aptus Mobile
Built-in GPS and NMEA 0183 Interface Port
The i4/i4P includes a built-in GPS inside of the Antenna Unit for faster signal acquisition. The ship’s GPS can also be connected through the NMEA 0183 port on the rear panel of the ACU.
Automatic Polarization (Skew-angle) Control *i4P Only Automatic Skew Angle Control System (-90°~ +90°) for Linear Horizontal/ Vertical Polarization.
Constant and Seamless Entertainment
- Intellian’s super-efficient 45cm (17.7 in) diameter antenna
- Always maintains the highest signal strength available to ensure crystal-clear TV reception
- Dynamic Beam Tilting (DBT) technology and Wide Range Search (WRS) algorithm for quick and quiet signal tracking
Automatic Satellite Switching
- DISH (US) and Bell TV (Canada) users will benefit from using an Intellian MIM (Multi-Satellite Interface Module)
- The MIM is required to facilitate automatic switching between satellites for these services
- Allowing boaters to enjoy changing channels with automatic satellite switching just like a home system
