VE-SP1 Icom IC-5301 Speakerphone Unit, PTT Desktop, External Speaker and Microphone
VE-SP1 Icom IC-5301 Speakerphone Unit, PTT Desktop, External Speaker and Microphone
Compatibility:
- IC-5301H
Included in this Pack:
- Connection cable (OPC-2397)
- External microphone (SM-1)
- Power adapter (BC-242)
- Alkaline batteries are not supplied.
Features – Teleconference Call System for the Icom IP5301H Transceiver
- The VE-SP1 is the option for the Icom IP503H transceiver.
- For compatible models, see the Icom website.
- For IP transceiver operation, see the IP transceiver manual posted on the Icom website.
- External microphone (supplied) and external speaker (option) are available
- Battery pack BC-242 can be charged when the power adapter is connected
- You can use the VE-SP1 with AA (LR6) size alkaline batteries(The AA battery pack cannot be charged)
Specification
Input voltage: 12 ~ 16 V DC or the specified Icom power adapter (BC-242)
Operating temperature range: −10°C ~ +60°C, 14°F ~ 140°F ( When using the power adapter: 10°C ~ 40°C, 50°F ~ 104°F)
Current drain:
Stand-by power: AF output power: Less than 1.0 A 600 μA (When using alkaline batteries) More than 1.1 W at 10% distortion with an 8 Ω load Microphone output level: 5 mVrms ± 20% ( Microphone input level: 10 mVrms (Measurement condition: 1 kHz))
Charging current: 700 mA ± 10% (rapid charging)
Dimensions (approximate): 216.8 (W) × 52.8 (H) × 173.3 (D) mm, 8.5 (W) × 2.1 (H) × 6.8 (D) inch (projections not included)
Weight (approximate): 595 g, 1 lb 5 oz (without the supplied accessories)
